Aaeon ACP-5182 Manuel utilisateur
Multi-Touch Panel PC ACP-5182
ACP-5182
18.5” Intel®AtomTM D510
Processor
High Brightness
Fanless Multi-Touch Panel PC
ACP-5182 Manual 1st Ed
January 2011
Multi-Touch Panel PC ACP-5182
i
Copyright Notice
This document is copyrighted, 2011. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties, which may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON, assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
Multi-Touch Panel PC ACP-5182
ii
Acknowledgments
zIntel®, AtomTM are registered trademarks of Intel®Corporation.
zMicrosoft®Windows is a registered trademark of Microsoft®
Corporation.
zRTL is a trademark of Realtek Semi-Conductor Co., Ltd.
zC&T is a trademark of Chips and Technologies, Inc.
zUMC is a trademark of United Microelectronics Corporation.
zITE is a trademark of Integrated Technology Express, Inc.
All other product names or trademarks are properties of their
respective owners.
Multi-Touch Panel PC ACP-5182
iii
Packing List
Before you begin installing your Medical Station, please make
sure that the following items have been shipped:
ACP-5182 Infotainment Multi-Touch Panel PC
HDD screws
Product DVD
Contains User’s Manual (in PDF format), Drivers and
Utilities
If any of these items are missing or damaged, you should contact your
distributor or sales representative immediately.
Multi-Touch Panel PC ACP-5182
iv
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation.
Dropping it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.
Multi-Touch Panel PC ACP-5182
v
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to
work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY
DAMAGE THE EQUIPMENT.
16. External equipment intended for connection to signal
input/output or other connectors, shall comply with relevant
UL / IEC standard (e.g. UL 1950 for IT equipment and
UL 60601-1 / IEC 60601 series for systems – shall comply with
the standard IEC 60601-1-1, Safety requirements for medical
electrical systems. Equipment not complying with
UL 60601-1 shall be kept outside the patient environment, as
defined in the standard.
Caution:
It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type
recommended by the manufacturer.
Multi-Touch Panel PC ACP-5182
vi
Classification
1. Degree of production against electric shock: not classified
2. Degree of protection against the ingress of water: IPX0
3. Equipment not suitable for use in the presence of a flammable
anesthetic mixture with air or with oxygen or nitrous oxide.
4. Mode of operation: Continuous
5. Type of protection against electric shock: Class I equipment
Multi-Touch Panel PC ACP-5182
vii
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device
must accept any interference received
including interference that may cause
undesired operation.
Multi-Touch Panel PC ACP-5182
viii
UL Module Description
ACP-5182 AC modules are developed to
suitable for the Classification Mark
requirement
Multi-Touch Panel PC ACP-5182
ix
Safety Symbol Description
The following safety symbols are the further explanations for your
reference.
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1
Attention, consult ACCOMPANYING
DOCUMENTS.
Ground wire ound wire.Protective Gr
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1
