PLATINUM II
89
MOTION SENSOR/TIMER SET UP
9. Multiple Timer Configuration
When configured correctly, pressing a Timer button switches on the A/C and
opens the corresponding Zone Damper to 100% (or desired Max %, which can be
adjusted using the Zone Balance feature) for the set time period. All other Zone
Dampers remain closed. Pushing any other Timer button will open the
corresponding Zone Damper and extend the A/C operation by the set time
period. A second press on an active Timer will halt the countdown for that Zone
and close the corresponding Zone Damper. Once all the Timers expire, the A/C is
switched off and all Zone Dampers are closed.
NOTE: The assumption is the A/C wall control and the Platinum II Touch Screen
will only be accessible to the installer and not the end user of the Timer.
ŸIf A/C system is turned on or off at the wall control, there is no effect on the
Timer countdown, if active.
ŸIf the Platinum II system is turned off at the Touch Screen, all Zone Dampers
will open – if the A/C is on, every Zone will get air regardless of the Timer
status.
NOTE: If Timers are used without the link to the A/C, the duct system may need
to be designed with appropriate Relief Zones, so that if all the Zones are closed,
the A/C will not be damaged.
For the Platinum II system to know if it is in Heating or Cooling Mode requires an
Auto system configuration with the use of a Duct Sensor and temperature
Sensors in each room.
To A/C
Timer - Zone 1 Timer - Zone 2 Timer - Zone 3
SIPSRMC04RMC04
Link Cable
TS01 TS01 (optional)
Zone 1
Zone 2
Zone 3
MULTIPLE TIMER CONFIGURATION MULTIPLE TIMER FUNCTION
(optional)
