70mai Wireless Car Charger Mount User Manual
Product Overview
Wireless car charger mount
LED
indicator
Micro USB
connector
Settings Settings
Please read the manual carefully before using the product, and
keep it in a safe place.
Installation
Scan the QR code below to obtain the installation guideline.
LED Indicator
OffWireless charging abnormal
Flashing greenWireless charging in progress
Steady greenMount is connected to the power supply
OffMount is not connected to the power supply
Status LED indicator
Instructions
1. Insert the provided standard Micro USB cable in the Micro
USB connector of the mount, and connect the unit to the car
charger adapter. Then insert the car charger adapter into the
cigarette lighter socket for power supply.
2. To use the wireless charging function, place the cellphone in
the mount. Then adjust the settings. Make sure the center of
the back of the cellphone and the center of the built-in
wireless coils of the mount are aligned.
Wireless Charging
This product has three settings to accommodate different types
of cellphones. Scan the QR code below to obtain information on
cellphone type and settings adjustment.
Settings Adjustment
Adapter Requirements
5V 2A car charger adapter. Support 5W normal charge.
QC2.0 / QC3.0 car charger adapter. Support 10W quick charge.
Do not support 5V 1A car charger adapters.
Precautions
1. The wireless charging function of this product should only be use
with cellphones with a wireless charging function.
2. Please install this product correctly. Wireless charging will raise the
temperature of the mount. Therefore, make sure the device has good
ventilation. We shall not be responsible for any losses caused by
incorrect installation of this product.
3. When the cellphone is connected to the charger via a cellphone
data cable, the wireless charging function will be disabled.
4. To avoid problems associated with specification mismatch, please
use the provided standard Micro USB cable. We shall not be
responsible for any losses caused by using a cable which is not the
provided standard Micro USB cable.
5. To ensure a better result, please use this product within the
temperature range of 0℃ ~ 40℃.
6. Keep it away from any strong magnetic fields, which may damage
this product.
7. Do not disassemble this product on your own.
8. Do not expose this product to strong impact or vibration, which may
damage this product and cause malfunction or stop it from working.
9. Do not clean this product with a chemical solvent or cleaner.
10. Please only use this product within the scope permitted by law.
11. Keep the product at least 20cm away from the driver and
passengers.
FCC Note:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and(2) this device
must accept any interference received, including interference that may
cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with a minimum distance of 20cm between the radiator
& your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Package Contents
70mai wireless car charger mount ×1
Micro USB cable ×1
User manual ×1
Service: [email protected]
For further information, please go to www.70mai.com
Manufactured by: 70mai Co., Ltd.
Address: Room 2220, Building 2, No. 588 Zixing road, Minhang
District, Shanghai, CHINA
Model: Midrive PB01
Dimensions: 96.8 x 105.8 x 58.8mm
Input connector: Micro USB
Input: 5.0V 2A / 9.0V 1.6A
Output: 5.0V 5W MAX / 9.0V 10W MAX
Transmission distance: ≤4mm
Operating temperature range: 0℃ ~ 40℃
Specifications
