5Core Pro Series Guide de démarrage rapide
15” Active Amplifier (Rechargeable)
O P E R A T I O N A L M A N U A L
15”Active Amplifier incorporates high-tech design and
circuitry with high quality performance and
absolute reliability.
• Thank you for purchasing 5CORE PA Amplier.
• Please read this manual thoroughly before making connection and turning on the power. Following
the instructions in this manual will enable you to obtain optimum performance from your new 5CORE
PA Amplier.
• Please retain this manual for future reference. www.5core.com
MADE IN INDIA
Thanks for using amplifiers.
For any assistance/suggestion
visit us at www.5core.com.
Specifications
TYPE
Power Source
Power Output
Gain
Frequency Response
Tone Controls
Signal to Noise ratio
XLR Electronically balanced discrete signal
AC: 220-240V 50/60Hz
DC: 12V Inbuilt (Rechargeable)
80W Max
60W RMS at 10% THD
50W RMS at 5% THD
+10dB to +60dB
<10Hz-120KHz(-1dB)
<10Hz-180KHz(-3dB)
BASS:- ±10db at 100Hz
TREBLE:±10db at 10kHz
110dB/112dB
Page 1Page 4
Product's look may be vary from given actual photo.
ISO 9001:2015
M5400913IN
CERTIFICATE NO.: 16RQ07AY
Back Panel Controls & Features Guideline to Operate the Amplifier
1. Place the Amplier in dry and well ventilated place. Considerable heat is
generated inside the amplier during continuous use, therefore do not block the
air ventilation holes of the active amplier.
2. Only good quality Low impedance microphones like 5 CORE 5CM-ND 780X, ND
99X or ND series to be used to avoid / reduce feedback & howling. This will help
obtaining satisfactory power output from Amplier without howling or feedback.
3. It is advised to keep the master Control of the Amplier at’0’ position before
switching ‘ON’ the Amplier & later may be moved to optimum position say ‘6 to 8’.
Safety Instructions
• WATER AND MOISTURE: In order to prevent any re or shock hazard, do not
expose this equipment to rain or moisture.
• POWER SOURCE: The equipment should be connected to a 220-240V 50/60Hz.
• POWER CORD PROTECTION: Do not cut, damage or modify the power cord
supplied with the equipment, keep the power supply cord away from heaters and
harmful chemicals. Do not place heavy objects on the power cord.
• Operation on Generator: When operating the Amplier on a generator, make
sure it is switched ‘OFF’ till the generator voltage has stabilized and then only
switch the amplier ‘ON’.
• VENTILATION: The amplier should be situated so that its location or position
does not interfere with its proper ventilation, Also do not insert or drop anything
into the ventilation holes.
• PREVENTION OF LOSS IN SPEAKER CABLES: Always use thick cables for low
impedance speakers connections, Use of cable type 23/38 or thicker is
recommended as heavy current ow through the cables.
• GROUNDING OR EARTHING: The equipment must be earthed properly before
operating it to avoid electric shock. A wire from the earth terminal must be
connected to either water pipe or to electrical earth for safe operation.
Page 3Page 2
• Provision for both AC and inbuilt DC 12V (Rechargeable) Battery Operation
ensures continuity of program.
• MIC-1 to MIC-2 are provided with individual Volume Control.
• BASS, TREBLE & Echo controls provided for shaping tonal quality of music
& speech as desired.
• MASTER control permits adjustment of overall volume of program inputs.
• Protection against wrong battery polarity-provided.
• Audio output & input provision
• Seperate tone control provided for volume/treble/bass/echo/mic/guitar.
• Seperate tone control provided for Mic Treble and Mic Bass.
• Inbuilt neodymium tweeter.
• Wireless hand microphone & head microphone
• Bluetooth module with recording feature.
1. VOLUME : Slide shortly to volume level+ & volume level-.
2. MODE : To select All Modes (AUX/ /MMC/Bluetooth).
4. PREVIOUS : Press shortly to select the previous song in /MMC
mode.
5. PLAY/PAUSE : Press shortly to Play/Pause the song in /MMC mode.
Press for 3 second to auto scanning in FM mode.
6. NEXT : Press shortly to select the next song in /MMC mode.
Note: Due to continuous upgradation, specifications and features may
change without intimation of prior notice.
Speaker and Tweeter used in Amplifier
FR 15120
Frame: MS, 15”
Cone: Paper body with cotton edge
Impedance: 4W
Max Power: 850PMPO
Magnet: 120X57X20
Voice Coil: 1.5” Voice coil with Aluminium heat sink
Neodymium magnet
ND-T01
