512 Audio SCRIPT Manuel utilisateur
SCRIPT
PREMIUM USB MICROPHONE FOR PODCASTING,
STREAMING, AND RECORDING
EN | FR | DE | ES | 中文 | 日本語
TABLE OF CONTENTS
English...................................................................................... 3
French .....................................................................................15
Deutsch................................................................................... 27
Español ...................................................................................39
中文 .......................................................................................51
................................................................................... 63
EN | 3
WELCOME
Congratulations on becoming an owner of Script, a premium USB microphone
for podcasting, streaming, or recording. Script delivers broadcast-quality audio
in an elegant, minimalist design that looks as good as it sounds. With plug ‘n play
compatibility, it’s never been easier to start streaming in a matter of minutes on any Mac
or PC. Script features a zero-latency stereo headphone output, adjustable volume,
push-button mute, a dedicated pickup pattern switch, and an LED status indicator so
you can know if you’re muted at a glance. Script brings the most important elements of
a broadcast studio to your desk so you can sound your best wherever you are.
4 | EN
FEATURES
DUAL CAPSULES
Two 14mm electret condenser capsules deliver smooth, clear sound for podcasting,
streaming, and video-conferencing.
ZEROLATENCY STEREO HEADPHONE OUTPUT
Script features an industry-standard ¹/” headphone jack for simple and easy zero-
latency monitoring for when you’re recording, streaming, or in a meeting.
HEADPHONE VOLUME CONTROL
Quickly adjust the volume of your headphones with the dedicated volume knob on the
front of the microphone.
MUTE BUTTON
Press the headphone volume knob to instantly mute or unmute your microphone. A white
EN | 5
FEATURES
LED indicates when the mic is active. A red LED indicates that your Script is muted.
ARM MOUNT
Script includes an arm mount adapter that screws onto the base of the microphone
body. Once secured in place, you can easily attach Script to most boom arms,
microphone stands, and desktop mounts.
USBC CONNECTION
Script connects to any Mac or PC with the included USB-C to USB-A cable.
PATTERN SELECTION
Switch between cardioid and omni with a simple toggle switch on the back of Script.
6 | EN
GETTING STARTED WITH SCRIPT
First, remove Script from its packaging and attach the included arm mount to the bottom
of the microphone. Rotate and tighten as needed so that the 512 logo and headphone
volume knob are facing you and the microphone is firmly attached to the arm mount.
You are now ready to attach Script to a microphone boom arm, mic stand, or desktop
mount. Once mounted to your mic stand of choice, connect Script to your computer
with the included USB-C to USB-A cable. The headphone volume knob/mute button
should illuminate, which indicates that the microphone is now powered.
When you are ready to record or begin streaming, confirm that the 512 Audio logo
and volume knob are facing you. Next, position the microphone a few inches away
from your mouth.
That’s it! You’re all set to capture your voice with broadcast-quality audio. Enjoy!
EN | 7
GETTING STARTED WITH SCRIPT
WINDOWS QUICKSTART GUIDE
(Windows 7, 8.1, 10, or newer)
1. Connect Script to your PC with the included USB cable.
2. Click Start (or the Windows logo), then select Control Panel.
3. Once you open Control Panel, select the “Sound” icon.
4. Click the “Recording” tab and select “Script”.
5. Click the “Playback” tab and select “Script”.
8 | EN
GETTING STARTED WITH SCRIPT
MAC OS QUICKSTART GUIDE
(macOS 10.10 or newer)
1. Connect Script to your Mac with the included USB cable.
2. Open System Preferences and select the “Sound” icon.
3. Click the “Input” tab and select “Script”.
4. Click the “Output” tab and select “Script”.
5. On the same screen, locate the “Output” volume and set to 100%.
EN | 9
POPULAR SOFTWARE COMPATIBILITY
It’s easy to use Script with your favorite software. With universal compatibility, you can
start recording great audio right out of the box. Script works seamlessly with the apps
you already use including Garageband, iMovie, Zoom, Facetime, Skype, Audacity,
Logic Pro, and more. Just plug into your Mac or PC, choose Script as your audio input
in the software of your choice, and begin to capture broadcast-quality audio. Script
does not require any drivers, it’s that simple.
10 | EN
POLAR PATTERNS
Script’s unique dual-capsule design gives you the flexibility to choose the right pickup
pattern in any scenario.
CARDIOID
Recommended for recording podcasts, live-streaming, singing, and voiceovers. The
cardioid pickup pattern records sounds that are directly in front of the microphone and
rejects ambient noise around you.
OMNIDIRECTIONAL
Ideal for multi-person podcasts, a group conference call, or when you want to capture
the ambience of a live performance. The omnidirectional pickup pattern captures sound
from all around the mic, ideal for multi-person content or calls.
