4IPNET EAP330 Manuel utilisateur

EAP330

Enterprise Access Point

Handbook

EAP330 Enterprise Access Point ENGLISH

This document is protected by USA copyright laws and other laws. Besides, the

document is the property of 4IPNET, INC. You may not copy, reproduce, distribute,

publish, display, perform, or modify any part of this publication in any form or by any

means without prior written permission from 4IPNET, INC. You may not alter or remove any

are claimed or registered marks of their respective companies or organizations.

To download up-to-date version, please visit www.4ipnet.com.

Handbook

EAP330 Enterprise Access Point ENGLISH

FCC CAUTION

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications not expressly approved by the party responsible for compliance could void the

user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or

transmitter.

For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other

channels is not possible.

This device is restricted to indoor use when operated in the 5.15 to 5.25 GHz frequency range.

※FCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the

potential for harmful interference to co-channel Mobile Satellite systems.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Handbook

EAP330 Enterprise Access Point ENGLISH

iii

CE CAUTION

Declaration of Conformity with Regard to the 1999/5/EC (R&TTE Directive) for

European Community, Switzerland, Norway, Iceland, and Liechtenstein

Model: EAP330

For 2.4 GHz radios, the device has been tested and passed the requirements of the following standards, and

hence fulfills the EMC and safety requirements of R&TTE Directive within the CE marking requirement.

• Radio: EN 300.328:

•EMC: EN 301.489-1, EN 301.489-17,

• EMC: EN 55022Class B, EN 55024:+ A1 + A2including the followings:

EN 61000-3-2, EN 61000-3-3.

EN 61000-4-2, EN 61000-4-3, EN 61000-4-4,

EN 61000-4-5, EN 61000-4-6, EN 61000-4-11

• Safety: EN 60950-1 + A11,

Caution:

This declaration is only valid for configurations (combinations of software, firmware, and hardware)

provided and supported by 4ipnet Inc. The use of software or firmware not provided and supported by

4ipnet Inc. may result in the equipment no longer being compliant with the regulatory requirements.

European standards dictate maximum radiated transmit power of 100mW EIRP and frequency range

2.400-2.4835 GHz. This equipment is intended to be used in all EU and EFTA countries. Outdoor use may be

restricted to certain frequencies and/or may require a license for operation. Contact your local regulatory

authority for compliance.

Taiwan NCC Statement

根據 NCC 低功率電波輻射性電機管理辦法規定:

第十二條

經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或

變更原設計之特性及功能。

第十四條

低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善

至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受

合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

在5.25 ~ 5.35 秭赫頻帶內操作之無線資訊傳輸設備，限於室內使用。

減少電磁波影響，請妥適使用

Handbook

EAP330 Enterprise Access Point ENGLISH

Preface

Package Contents

4ipnet EAP330 is a high-end, dual radio 802.11

b/g/n + ac MIMO Access Point (AP) with the best

performance for business and industrial applications

and is compliant with the latest industrial wireless

security standards that are required in the tightly

secured enterprise network environments.

EAP330 makes the wireless communication fast,

secure and easy. It supports business grade

security such as 802.1X, and Wi-Fi Protected

Access (WPA and WPA2). The EAP330 supports

multiple point-to-point wireless links to form wider

wireless network coverage.

EAP330 also features multiple ESSIDs with VLAN

tags and multiple Virtual APs; great for enterprise

applications, such as separating traffic from different

departments using different ESSIDs. The PoE

Uplink port is able to receive power from Power over

Ethernet (PoE) sourcing devices.

This Handbook provides instructions and reference

materials to get you started with 4ipnet EAP330.

1. 4ipnet EAP330 x 1

2. Handbook x 1

3. PowerAdaptor (12V) x 1

4. Detachable Antenna x 6

It is recommended to keep the original

packing material for possible future shipment

when repair or maintenance is required. Any

returned product should be packed in its

original packaging to prevent damage during

delivery.

Handbook

EAP330 Enterprise Access Point ENGLISH

System Overview

External Antenna

External antennas via SMA connectors.A(1),A(2) and A(3) corresponds to

Ant1, Ant2 and Ant3 of 2.4G; B(1), B(2) and B(3) corresponds to Ant1,

Ant2 andAnt3 of 5G.

12V 2.5 A

Attach power adaptor here.

Uplink (PoE) Port

Offers uplink connection. This port can be used to connect to a controller,

gateway, or directly to the Internet. 802.3at PoE is also supported.

LAN 1 Port

The ports for connections with LAN side devices.

USB Port

USB interface reserved for future use.

WES Buttons

For IT administrators to easily setup WDS links with RF Card (A).

Handbook

EAP330 Enterprise Access Point ENGLISH

Restart / Reset

Press once to restart the system; to reset the system to factory default

settings, hold for more than 5 seconds.

WES Buttons

For IT administrators to easily setup WDS links with RF Card (B).

Console Port

To access EAP330 via the console interface.

10.

LED Indicator

An LED indicator is available to show the power status.

11.

K-Slot

Use Kensington lock for anti-theft purpose.

Handbook

EAP330 Enterprise Access Point ENGLISH

Hardware Installation

Please follow the steps mentioned below to install the hardware of EAP330:

1. Place the EAP330 at the best location.

The best location for EAP330 is usually at the center of your intended wireless network.

2. Connect the EAP330 to your network device.

Connect one end of the Ethernet cable to the Uplink port of EAP330 and the other end of the cable to a switch,

a router, or a hub. EAP330 is then connected to your existing wired LAN network.

3. There are two ways to supply power over to EAP330.

(a) Connect the DC power adapter to the EAP330 power socket.

Please use only the power adapter supplied with the EAP330 package. Using a different power

adapter may damage this system.

(b) EAP330 Uplink port is capable of receiving DC currents. Connect an IEEE 802.3at-compliant PSE

device, e.g. a PoE-switch, to the Uplink port of EAP330 with the Ethernet cable.

Now, the Hardware Installation is complete.

Using a different power adapter may damage this system.

To verify the wired connection between EAP330 and you switch / router / hub, please also

check the LED status indicator of the respective network devices.

Handbook

EAP330 Enterprise Access Point ENGLISH

Getting Started

4ipnet EAP330 supports web-based configuration. When hardware installation is complete, EAP330 can be

configured through a PC by using a web browser such as Mozilla Firefox 2.0 or Internet Explorer version 6.0

and above.

The default values of LAN IP address and subnet mask of EAP330 are:

IP Address: 192.168.1.1

Subnet Mask: 255.255.255.0

Steps:

1. To access the Web Management Interface, connect the administrator PC to the Uplink port of EAP330 via

an Ethernet cable. Then, set a static IP address on the same subnet mask as EAP330 in TCP/IP of your

PC, such as the following example:

IP Address: 192.168.1.100

Subnet Mask: 255.255.255.0

2. Launch the web browser on your PC by entering the IP address of EAP330 (http://192.168.1.1) in the

address field, and then press Enter.

Example of entering EAP330's default IP Address via a web browser

3. The following Admin Login Page will appear. Enter “admin” for both the Username and Password fields,

and then click Login.

Handbook

EAP330 Enterprise Access Point ENGLISH

Administrator Login Page

4. After a successful login to EAP330, a System Overview page of the Web Management Interface will

appear, as depicted below.

The Web Management Interface - System Overview Page

5. To logout, simply click on the Logout button at the upper right hand corner of the interface to return to the

Administrator Login Page. Click OK to logout.
