3One data 1100 Manuel utilisateur

Your

Serial and Data Communications Expert

Shen zhen 3onedata Technology Co.,Ltd

Model1100

10/100M

Media

Converter

(SM

MM)

ntroduction

Model1100, 10/100M Media Converter, provide s a cost effective

plug-and-play solution for long-range 10Base-T or 100Base-TX

Ethernet extensions and added benefit of 10/100 auto-negotiation,

making it the perfect choice when planning future upgrades of

10Base-T networks. M odel1100 Ethernet Fiber converters are ultra-

miniature in size and feature a shielded RJ45 Ethernet jack,

SC /ST/FC style fiber-optic connections. Built-in auto-sensing

capabilities enable full or half-duplex Ethernet operation with no

configuration required!

Packing

ist

Model 1100 is shipped with following items.

1. Model1100 ×1

2. 5VDC power adapter ×1(Media converter/5VDC)

3. User manual ×1

eatures:

1. Accord to IEEE802. 1 10Base-T , IEEE802.3 u 100Base-TX,

IEEE802.3 100Base-FX

2. MDI/MDI-X auto negotiation, 10M/100M auto negotiation

3. Supports full /half duplex, Point-to-point transparent transfer

4. Power External 5VDC input

5. Plug-and-play, easy to installation

6. Can insert to 2U 19", 14 slots Rack mount(power external)

inout

Configuration:

Power

Model1100 adopt the power supply input is 5VDC external.

Your

Serial and Data Communications Expert

Shen zhen 3onedata Technology Co.,Ltd

Ethernet(RJ45),Optical

fiber

interface

Optical

fiber

interface:

Optic fib er interface need use in pairs, OUT port is fiber send side

connect another long-range light of interface fiber receive end IN;

IN port is fiber receive side

connect long-range same fiber send

side :

Optic fib er s spent both ends mark the label (the following picture

show: A-A, B-B, can also mark another: A1-A2, B1-B2), in order to

use.

NOTE:

SC, ST or FC, for optic fiber interface, SM is look the same

to MM for form. For example,Model 1100 SM/SC,the optic fiber

interface(SC) is look the same to Model 1100 MM/SC.

Ethernet

interface:

Ethernet( RJ45 ) interface supports MDI/MDI-X auto negotiation,

can use straight- through cable connect PC or server, use across-

over connect cable Switch or HUB.

Your

Serial and Data Communications Expert

Shen zhen 3onedata Technology Co.,Ltd

MDI: PIN 1, 2, 3, 6 connects opposite.

MID-X: 1 → 3

2 → 6

3 → 1

6 → 2

MDI/MDI-X 10Base-T/100Base-TX P IN define as follow:

Note

：

“TX ±” Transfer data ±

，

“RX ±” Receive data ±

，

“—” None 。

MDI:

MDI-X:

MDI

MDI-X

TX+

RX+

TX-

RX-

RX+

TX+

RX-

TX-

4、5、7、8

—

(

- )

(

- )

(

- )

(

- )

1 8

Your

Serial and Data Communications Expert

Shen zhen 3onedata Technology Co.,Ltd

LED

indications:

Specifications:

Standards : comply with IEEE802. 1 10Base-T

IEEE802.3 u

100Base-TX, IEEE802.3 100Base-FX

RJ45 port rate: 10/100Mbps auto negotiation

Optic port rate: 100Mbps

Transfer distance: RJ45port: 100m

Fiber optic:20,40,60,80,120km(SM),

2, 5 km(MM) optional

RJ45 port cable: UTP 5E

Fiber connector: 2 ×SC, 2 ×

ST,

2×FC optional

Fiber optic cables:Single Mode:8.3/125,8.7/125,9/125 or 10/125 um

Muti-Mode:50/125,62.5/125 um

Wavelength:850nm,1310nm,1550nm

LED

STATE

INDICATION

PWR

(Power)

OFF

Power Off

BRIGHT

Power On

100

(10/100M)

OFF

10M Ethernet

BRIGHT

100M Ethernet

(Fiber Link Port)

OFF

Fiber Optic Unit is Faulty

BRIGHT

Fiber Optic Unit is Functional

Link/Act

(TX)

(TX Port

Link/Activity)

OFF

Ethernet is not Connected

FLASHING

Transmitting or Receiving Data

BRIGHT

Ethernet is Connected

Link/Act

(FX)

(FX Port

Link/Activity)

OFF

Fiber Links are not Connected

FLASHING

Transmitting or Receiving Data

BRIGHT

Fiber Links are Connected

FDX

(Full

Duplex/Collision)

OFF

Half-Duplex Mode or Network

Disconnected

FLASHING

Data Collision Detected

BRIGHT

Full-Duplex Mode

Your

Serial and Data Communications Expert

Shen zhen 3onedata Technology Co.,Ltd

Power supply: External 5VDC input

Dimensions: 94.0mm ×71.0mm ×26.0mm

Installation: support DIN-Rail installation

Operating temp:-10 °

to 65 ° C

Storage temperature: -20 to 70 ° C

Operating humidity : 5% to 95% (no condensation)

Warranty: 5 years

Approvals: FCC,CE, RoHS approvals

Applications

Extending

10/100M

Ethernet

data

distance

Installation

Model1100 provides DIN-rail and wall mounting two types of

installation.

Wall

mounting

installation

Your

Serial and Data Communications Expert

Shen zhen 3onedata Technology Co.,Ltd

DIN-Rail

Installation

Troubleshooting

instructions:

1. Make sure the power is connected and turned on.

2. Make sure the converter Ethernet and fiber optic cables are

connected properly.

3. Check the connections according to the connection diagram.

4. Check the LED Indication status and identify possible problems

from the Indication LED table above.

Note:

1. M ed ia C o n v e r t e r is a s e n s i t i v e e l e c t r on i c i t e m , p l e a s e d o

h a n d l e w i t h e x t r a c a r e o n d e l i v e r y , s h i ft i n g a n d h u m i d i t y .

2. T h is u n i t w i l l b e w a rr a n t y f o r 5 y e a r s .

3. W h ene v e r t he r e is a p r ob l e m r e g a r d i n g t h e q u a l i t y i ss u e w i t h i n

t h e w a rr a n t y pe r i o d , w e w i l l t a k e t h e r e s p on s i b i l i t y t o r e p a i r w i t h

f r e e .

4. A ft e r t h e w a rr an t y p e r i o d , w e w i l l c h a r g e a c c o r d i ng l y

d e pend i n g o n t h e f a u l t o r d a m a g e .

5. W h ene v e r t h e r e is a f au l t , y o u c a n c o n t a c t o u r t e c h n i c a l

s u p p o r t a f t e r y o u i d e n t i f y t h e p r o b l e m a n d t h e a l a r m .

Your

Serial and Data Communications Expert

Shen zhen 3onedata Technology Co.,Ltd

Common

Problems

PWR

power

supply

indicator

lamp

not

lighting

Cause:

1. Power supply not properly connected

2. Protector tube damaged

3. P ower input tie-line in reverse connection

4. Internal power supply circuit with failure

Solution

1. Check power switch and jack

2. Replace protector tube

3. Correct power supply line connection

4. Returned to the manufacturer for repair.

Port

Link/Act

indicator

lamp

not

lighting

Cause:

Optic fiber port link is fault.

Solution:

1. Check fiber optic is link or not.

2. Check fiber optic loss is high.

3. Clean the connector of optic interface.

4. Insert the well connector in place.

5. Returned to the manufacturer for repair.

Port

Link/Act

indicator

lamp

not

lighting

Cause:

Ethernet port link is fault.

Solution:

1. Check Ethernet(RJ45) line is link or not.

2. Check Ethernet(RJ45) port is loose.

3. Check the rate of selected media converter

4. Check the rate of Network.

5. Returned to the manufacturer for repair.

Network

packet

loss

Solution:

1. Check Ethernet rate or full/half duplex is matched or not.

2. Ethernet(RJ45) port is loose contact, or optic port is loose

contact and soiled .

3. Ethernet cable not comply with Ethernet standard.

Your

Serial and Data Communications Expert

Shen zhen 3onedata Technology Co.,Ltd

Certifications:

Shenzhen

3onedata

Technology

Co.,Ltd

Tel: +86-755-26702688 Fax: +86-755-26703485

www.3onedata.com
