Wireless Network Module EP8790NET

Operator’s Guide

For: 3M™ Multimedia Projector MP8790

Thank you for purchasing the EP8790NET wireless network module.

Please read this manual thoroughly to ensure proper and safe use of your new wireless network

module. Keep this manual in a safe place for future reference.

Summary

The EP8790NET wireless network module attaches

to 3M Multimedia Projector MP8790 and enables

users to make presentations using multiple

PCs in a cable-free environment.

Features

(1) Cable-Free Presentations

Wireless presentations made possible by

use of a wireless LAN card.

(2) Multiple Screens

Images from up to four PCs can be

presented simultaneously via the same

projector.

(3) Stand Alone Presentations

Now you can leave your PC behind and run

stand alone presentations with just a

memory card (sold separately).

(4) Remote Control via Your Web

Browser

Now you can use your Web browser to

remote control the projector.

Contents

Functions ....................................................2

EP8790NET Components ............................4

Attaching the EP8790NET Module to the Projector

....5

Installing the Software ................................9

Network Settings........................................11

Wireless Presentations

(Live Mode)..........15

Presentation Playback

(Playback Mode)..........19

Stand Alone Presentations

(PC-less Presentation Mode)..........19

Using ImageViewer ..................................20

Using FileViewer........................................23

Controlling the Projector via Your Web Browser

....25

Configuration Utility ..................................29

Changing Network Settings Directly from

the EP8790NET Module ............................32

Troubleshooting ........................................35

Specifications ............................................37

TRADEMARK ACKNOWLEDGEMENT :

•

VGA and XGA are registered trademarks of

the International Business Machines Corporation.

•

Windows is a registered trademark of Microsoft

Corporation.

• All other trademarks are the property of their

respective owners.

• The information in this manual is subject to change without notice.

• The manufacturer assumes no responsibility for any errors that may appear in this manual

•

The reproduction, transmission or use of this document or contents is not permitted without express written authority.

NOTE

3M™ Wireless Network Module EP8790NET

Operator's Guide

Introduction

Functions

The EP8790NET wireless network module is equipped with the latest network functions. You can use

the EP8790NET module in combination with 3M MP8790 Multimedia Projector to make presentations

that draw on the power of your network. In addition, the wireless LAN card (*1) allows you to connect

the EP8790NET module to your network without the need to connect any annoying LAN cables.

(*1): Please use the wireless LAN card that came with your EP8790NET.

1. Live Mode

The EP8790NET module gives you the power to present PowerPoint® and other presentations with

ease and in a cable-free environment.

Get your computer ready to go! Using the EP8790NET module with PCs that are equipped with the latest

wireless LAN functions allow you to project images from your PC in real time (*2) using wireless

transmission to project a large screen with the same feel as a live broadcast.

No more annoying cables! Not only that, but you can project presentations from multiple computers at

the same! In addition, you can now project a presentation from one computer to multiple projectors.

(*2):

This will depend on the type of images you are attempting to display. Images are refreshed at a rate

of every one to four seconds. Therefore, you might not be able to project extremely dynamic images

such as animation very smoothly, and, in some cases, you may not be able to project them at all.

Office meetings at a snap of the fingers! Up to four PC screens can be displayed at the

same time.

Meetings in a wireless environment! In your showroom or at a convention hall.

Example of a Multiple Screen

3M™ Wireless Network Module EP8790NET

Consult with your network administrator prior to attempting to connect to your company's LAN.

NOTE

2. Playback Mode

Images transmitted to the projector in Live Mode can be replayed from the projector side (*3).

You can also send images to the projector from the PC in advance (*4).

Regardless of the method chosen, you can select the image you wish to display or even select

multiple images for consecutive playback by viewing the corresponding thumbnail images

stored on the projector side (*5).

(*3): Use the key on your PC keyboard to capture images for replay in Playback mode.

(*4): Refer to for detailed information on how to use FileViewer.

(*5): Refer to for detailed information on how to use ImageViewer.

3. PC-less Presentation Mode (*6)

In order to use PC-less Presentation Mode, you need to store your presentation data (*7) into a

memory card (*8). Next, insert the memory card into the projector and you are all ready to make

a presentation with just the projector. No need for a PC! The presentation is played just as

described in Playback Mode.

(*6):

Since there is only one card slot, you can't use the wireless LAN card when in this mode.

(*7): You can only use still image files of the following extensions: .jpg, .bmp and .png.

(*8): You can use any of the following types of memory cards:

PCMCIA compliant memory card

CF memory card (dedicated PCMCIA adaptor required)

SD card (dedicated PCMCIA adaptor required)

Memory Stick (dedicated PCMCIA adaptor required)

HDD card (ATA compatible; less than 2GB) (IDE compatible HDD cards can't be used)

Microdrive (dedicated PCMCIA adaptor required; ATA compatible; less than 2GB)

(IDE compatible HDD cards can't be used)

Screen

Only memory cards under 2GB can be used. Memory cards formatted to 2GB or more can't be used.

Reformat memory cards to under 2GB as necessary. (Refer to your memory card user guide for details.)

NOTE

4. Remote Control Mode

The EP8790NET incorporates the latest LAN functions, enabling you to not only make presentations,

but also control the projector using a control panel that you interface to using your Web

browser. Remote control functions available include, turning the projector's power on and off,

and selecting between image sources.

This feature also provides you with such information as when the projector's lamp needs to be

replaced. Even if the projector is located in an office room away from your current location, you

can easily operate it via remote control.

If you opt not to use the wireless LAN card, you can still directly connect your computer

using a LAN cable. Be sure to use a cross cable when directly connecting to just one PC. Use

a straight cable for connecting to the closest hub of your company LAN.

3M™ Wireless Network Module EP8790NET

Introduction (continued)

EP8790NET Components

The EP8790NET wireless network module is composed of its main unit (1) and rear cover (2).

(1) Main unit:

Mounts onto the multimedea projector MP8790.

(2) Rear cover:

Remove this cover when mounting the EP8790NET module to a projector and then reattach once

the EP8790NET module is properly mounted onto the projector.

(3) Clasp:

Use this to secure the EP8790NET module in place. Tighten these once the EP8790NET module

is properly mounted onto the projector.

(4) LAN port:

The port used to connect to a network hub or directly to a PC using a LAN cable. This

connection can't be accessed when the wireless LAN card is in use. Remove the wireless

LAN card if you wish to use a cable-based LAN connection. (Only one LAN connection at a

time is allowed.)

(5) PCMCIA card slot:

(6) Card eject button:

This is the slot for inserting the PCMCIA compatible wireless LAN card or memory cards.

Insert cards slowly and carefully into this slot. Use this button to remove a card from the card

slot. After pressing this button, slowly remove the card.

(7) Power cable:

Use this cable to connect the module to the projector in order to supply power to the module.

(8) Power port:

Firmly plug the power cable into this port after the module is properly mounted onto the

projector.

(1) Main unit

(4) LAN port (5) PCMCIA card slot

(6) Card eject button (2) Rear cover

(8) Power port

(7) Power cable

(3) Clasp

(9) Locking screws

3M™ Wireless Network Module EP8790NET

Attaching the EP8790NET Module to the Projector

The EP8790NET module is designed exclusively for use with 3M Multimedia Projector MP8790. Please slowly and carefully

follow the below instructions when attempting to mount the EP8790NET module onto the projector.

(1) Turn off the projector by turning off its AC power switch.

(2) Remove the projector's filter cover.

Push both of the filter cover tabs down and then pull them to remove the filter cover.

(3) Remove the rear cover of the EP8790NET module.

Push the rear cover tabs down and then pull the rear cover to remove it.

(4) Fit the EP8790NET module's clasp into the projector's recess and align the module so that

it can connect to the DVI ports on the back of the projector.

➱

Recess

Clasp

Tabs

Filter cover

Rear cover

Rear cover tabs

DVI port

3M™ Wireless Network Module EP8790NET

Introduction (continued)

(5) Slowly slide the module into place (in the direction of the arrow). Make sure that the DVI port

is correctly aligned. (Please take care not to cause damage to the projector by the clasp.)

Insert the two module locking screws into the respective DVI port.

[(7) Tighten the screws]

(6) Tighten (turn right) the two DVI port locking screws.

(7) Tighten the clasp to the projector using the accompanying locking screws (M3x8).

(8) Firmly connect the module's power cable to the projector's power port

Power port

(9) Reattach the projector's filter cover.

Filter cover

3M™ Wireless Network Module EP8790NET

Confirming the Connection to the Projector

Once you have completed mounting the EP8790NET module onto the projector, follow the below instructions

to make sure that the connection to the projector is working okay. During this confirmation, you will check to see:

•

Whether or not the EP8790NET module is correctly recognized when the projector's menu is displayed

(1) Turn on the projector's power.

(Turn on the projector's AC switch and press the STANDBY button.)

(2) Select DVI using the projector's jog dial button or by pressing the WIRELESS button on the

projector's remote control.

STANDBY/ON

VIDEO

DOWN

BLANK

ASPECT

PUSH

LASER

INDICATOR

LASER

RGB

FOCUS

ENTER

OFF

ESC MENU RESET

POSITION

MAGNIFY VOLUME

MUTE

WIRELESS KEYSTONE

FREEZE

ONE TOUCH

AUTO

PinP

ZOOM PAGE

Press the stick for

ENTER move up for

or down for .

button

WIRELESS button

button

RESET

button

(3) Use the remote control or the projectors

operation panel to open the WIRELESS

menu (refer to the projector's operator's

guide as necessary):

•

Press the MENU button.

•

Press the button until the cursor is over

WIRELESS.

(4) Press the button. (5) Press the button twice.

➞

(6)

After a moment, the network information will be displayed as shown below. Confirm the network information.

If the information is not displayed, check the

connection between the EP8790NET module and

the projector.

NOTE

3M™ Wireless Network Module EP8790NET

Introduction (continued)

[IP Address:]

A unique numeric address used to identify each network device.

The IP's factory default setting is 192.168.100.10.

[Sub Net Mask:]

The network address portion of the IP address.

The factory default is 255.255.255.0.

[DHCP (Dynamic Host Configuration Protocol):]

This setting is used to determine whether to have this device's IP address assigned automatically

by the network's DHCP server or to assign the IP address manually (as described above).

The factory default is to leave this setting Off and assign the IP address manually.

[Ch (Channel):]

The wireless LAN (IEEE802.11b) device can communicate on channels 1 to 11. The factory

default is channel 10.

[Wireless Mode:]

Sets the communication mode to be used for wireless communication. The factory default setting

is 802.11 AD-HOC.

[WEP (Wired Equivalent Privacy):]

An encryption method used for wireless communication. The factory default is "Off," meaning that

encryption is not used.

[

Operation Mode:Use this to confirm the current operation mode of the EP8790NET module.

]

Live: The screen appearing on the PC is displayed on the projector.

Play Back: The images stored in the EP8790NET module are played.

PC-Less: The EP8790NET is ready to execute PC-less Presentation Mode using a memory card.

[PC Card: Displays the type of PC card currently inserted into the EP8790NET.]

[Speed:]

The wireless communication speed. The factory default is AUTO.

[SSID (Service Set Identity):]

The network group name (also referred to as ESSID).

The same name setting is used for the same network group.

This dialog displays the first 16 characters of the SSID. Please note that some symbols cannot be

displayed in this dialog.

[

MAC Ethernet: The fixed MAC address of the wired (cable-based) LAN device installed in this device.

]

[

MAC Wireless: The fixed MAC address of the wireless LAN card inserted in this device.

]

[

WEP Key: The common encryption key when the WEP (encryption) function is enabled for wireless LAN.

]

This is the encryption key used in common by the network group when the WEP (Wired

Equivalent Privacy) function is enabled.

When WEP is set to 40bit, this will be 10 hexadecimal characters. When WEP is set to 128bit, the

first six characters are set as a dummy header (00:00:00) and the remaining 26 characters

(except “:”) are the actual WEP key.

Please note that even if DHCP is enabled, the displayed address is the IP address that was

manually set, not the IP address assigned by the DHCP server.

NOTE

3M™ Wireless Network Module EP8790NET

Installing the Software

In order to use the EP8790NET with a PC for wireless presentations (Live Mode), you will first need

to install the accompanying software on all the PCs you will be using.

Minimum PC Hardware and Software Requirements

•OS: Windows 98, Windows 98SE, Windows Me, Windows 2000 Professional,

Windows XP

•Graphic Interface: DirectX 6.1a or higher; Video RAM 4MB or higher (8MB recommended)

•CPU: Pentium III (600MHz or higher recommended)

•Display: VGA 640x480 or higher (XGA 1024x768 recommended) 65,536

simultaneous colors or higher

•Memory: 64MB or higher (128MB or higher if using Windows XP)

•

Available Hard Disk Space:

10MB or higher

•Web browser: Internet Explorer®(4.0 or higher) or Netscape Communicator®4.5X,

4.7X, etc.

•CD-ROM drive

•Interface PC card slot (PCMCIA Type-II)

•IEEE802.11b wireless LAN PC card

Software Installation Procedure

1. Turn on the PC.

2. Shut down all applications.

3. Insert the accompanying CD-ROM into the PC's CD-ROM

drive.

4. After a moment, the Welcome to WNM Utilities Setup

dialog will appear as shown on the right. Press Next.

•Not required for PCs with built-in 802.11b wireless LAN

•

Depending on the type of wireless LAN card and PC you are using, the EP8790NET module may

not be able to communicate properly with your PC, even if the PC you are using is equipped

with built-in wireless LAN functionality.

Should communication problems occur, please procure a Wi-Fi certified wireless LAN card.

NOTE

If your PC is currently set to a resolution higher than XGA, please change it to XGA.

NOTE

If the Welcome to WNM Utilities Setup dialog doesn't appear, proceed as follows:

(1) Click on the Start button on the toolbar and select Run.

(2) Enter E:\software\setup.exe and then press OK.

If your CD-ROM drive is not drive E on your PC, you will need to replace E with

the correct drive letter assigned to your CD-ROM drive.

NOTE

3M™ Wireless Network Module EP8790NET

Table des matières

Autres manuels 3M Accessoires pour projecteur

3M HE100 Manuel utilisateur

3M SCP716W Manuel utilisateur

Manuels Accessoires pour projecteur populaires d'autres marques

Optoma

Optoma BX-AL133B Manuel utilisateur

PEERLESS

PEERLESS PE 1120 Mode d’emploi

Osram

Osram SIRIUS HRI Series Manuel

Presentation Switchers

Presentation Switchers PS111 Manuel utilisateur

Kramer

Kramer VIA GO Manuel utilisateur

Yamaha

Yamaha PJL-112 Manuel de la liste des pièces

Swedstyle

Swedstyle CL23AA02ZA25E Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric 236CB Manuel du propriétaire

Epson

Epson BrightLink 475Wi Manuel utilisateur

Acer

Acer WP100 Manuel utilisateur

i3 i3board Manuel utilisateur

CHIEF

CHIEF HB-43E Manuel utilisateur

Biamp

Biamp Modena Hub Manuel de service

NEC

NEC MP10RX Manuel utilisateur

Panamorph

Panamorph DCR-S3 Manuel utilisateur

Exact solutions

Exact solutions FRAME-EVO-P10 Manuel utilisateur

CHIEF

CHIEF VCM103S Manuel utilisateur

InFocus

InFocus LP70+ Mode d’emploi
