1. Product Description
In this section, we introduce the 2N®Indoor View product, outline its application options and
highlight the advantages following from its use. The section also includes safety precautions.
1.1 Product Description
1.2 Differences between Models and Associated Products
1.3 Terms and Symbols Used
1.4 Safety Precautions
1.1 Product Description
2N®Indoor Viewis a stylish, compact-design indoor IP/SIP unit providing audio and video
communication with the 2NIP intercoms. The device includes a panel with a touch layer on 3
mm thick hardened glass, speakerphone and high-quality microphone providing excellent
audibility and intelligibility, Ethernet interface for LAN connection and external power supply,
induction loop and doorbell connectors.2N®Indoor View is a top-quality, cost efficient and
easy to install and configure answering unit.One installation can combine variable answering
units manufactured by 2N Telekomunikace a.s.
2N®Indoor View is equipped with a specific user interface for an increased user comfort and
safety.
2N®Indoor View basic features
7" color LCD video display,
full duplex handsfree HD audio communication,
LAN interface with PoE supply option,
easy flush mounting,
the device can be combined in installations with 2N®Indoor Touch,2N®Indoor Compact
or2N®Indoor Talk answering units,
remote administration and configuration via 2N®Remote Configuration,
call setup option via 2N®Mobile Videoon a smartphone,
DND mode and parental lock,
remote door lock control,
time display at relax,
display of the current weather,
integrated administrator web interface,
external doorbell button input,
external power supply input,
induction loop output,
2N® Indoor View User Manual
4 / 132
•
•
•
•
1.2 Differences between Models and Associated Products
2N®Indoor View indoor units
2N Part No.91378601
Axis Part No. 02087-001
2N®Indoor View – black
Indoor answering audio/video unit with touchscreen
designed for all 2N IP intercoms
2N Part No. 91378601WH
Axis Part No. 02088-001
2N®Indoor View – white
Indoor answering audio/video unit with touchscreen
designed for all 2N IP intercoms
2N® Indoor View User Manual
5 / 132
•
•
•
•
Other Indoor Units and Accessories
Part Numbers:
2N Part No.
91378375
Axis Part No.
01668-001
2N Part No.
91378376
Axis Part No.
01670-001
2N®Indoor Touch 2.0– black
WiFi version (third and fourth Part Nos.)
2N®Indoor Touch 2.0, an elegant indoor touch panel, is designed for
all of the 2N IP intercoms. The display panel shows you the person
standing at your door and helps you make conversation with the
visitor, open the door lock or switch on the entrance hall lights.
2N Part No.
91378382
Axis Part No.
01425-001
2N®Indoor Touch – desk stand black
2N® Indoor View User Manual
6 / 132
•
•
•
•
Part Numbers:
2N Part No.
91378375WH
Axis Part No.
01669-001
2N Part No.
91378376WH
Axis Part No.
01671-001
2N®Indoor Touch 2.0– white
WiFi version (third and fourth Part Nos.)
2N®Indoor Touch 2.0, an elegant indoor touch panel, is designed for
all of the 2N IP intercoms. The display panel shows you the person
standing at your door and helps you make conversation with the
visitor, open the door lock or switch on the entrance hall lights.
2N Part No.
91378382W
Axis Part No.
01426-001
2N®Indoor Touch– desk stand white
2N® Indoor View User Manual
7 / 132
•
•
•
•
2N Part No.
91378501
Axis Part No.
01935-001
2N®Indoor Compact – black
Indoor answering audio/video unit with touchscreen designed for all
2N IP intercoms
2N Part No.
91378501WH
Axis Part No.
01936-001
2N®Indoor Compact – white
Indoor answering audio/video unit with touchscreen designed for all
2N IP intercoms
2N® Indoor View User Manual
8 / 132
•
•
•
•
•
•
2N Part No.
91378401
Axis Part No.
01698-001
2N®Indoor Talk – black
Indoor answering audio unit with touchscreen designed for all 2N IP
intercoms
2N Part No.
91378401WH
Axis Part No.
01699-001
2N®Indoor Talk – white
Indoor answering audio unit with touchscreen designed for all 2N IP
intercoms
Mounting Accessories
2N Part No.
91378800
Axis Part No.
01700-001
Installation box for 2N indoor answering units for installation in a wall
or plasterboard.
Not included in the 2N®Indoor View package.
2N® Indoor View User Manual
9 / 132
•
•
•
•
2N Part No.
91378803
Axis Part No.
02320-001
Wall mounting box for 2N answering units
Not included in the 2N®Indoor View package.
2N Part No.
91378802
Axis Part No.
02039-001
Stand for the 2N indoor answering unit.
Not included in the 2N®Indoor View package.
2N® Indoor View User Manual
10 / 132
•
•
•
•
VoIP Phones
2N Part No. 91378358
Axis Part No. 01421-001
Grandstream GXV3240 VoIP video telephone
GXV3240 is the successor to the popular GXV3140
model, which provides comfortable video calls in
the IP network. Touchscreen and keypad control.
2N Part No. 91378357
Axis Part No. 01422-001
Grandstream GXV3275 VoIP video telephone
GXV3275 is the successor to the popular GXV3175
model, which provides comfortable video calls in
the IP network. Touchscreen control.
