Philco PD 1046 ET Manuel utilisateur

Dishwasher

OWNER’S MANUAL

PD 1046 ET

PD 1046 ETDX

Dear customer,

Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all

the instructions in this user’s manual.

EN - 1

CONTENTS

PART 1: SAFETY PRECAUTIONS......................................................................................................................2

PART 2: DISHWASHER FEATURES...................................................................................................................5

PART 3: INSTALLING THE MACHINE...............................................................................................................6

PART 4: BEFORE USING THE APPLIANCE.....................................................................................................10

PART 5: LOADINGYOUR DISHWASHER .......................................................................................................14

PART 6: PROGRAMME TABLE........................................................................................................................17

PART 7: THE CONTROL PANEL ......................................................................................................................19

PART 8: CLEANING AND MAINTENANCE.....................................................................................................22

PART 9: TROUBLESHOOTING........................................................................................................................24

PART 10: TECHNICAL SPECIFICATIONS .......................................................................................................27

PART 11: PRODUCT INFORMATION SHEET .................................................................................................28

EN - 2

PART 1: SAFETY PRECAUTIONS

WARNING! Please adhere to the precautions below when using

the dishwasher:

This appliance can be used by children aged from 8 years and

above and by persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instructions concerning use of the appliance

in a safe way and if they understand the hazards involved.

Children must not play with the appliance.

Cleaning and user maintenance cannot be performed by children

without supervision.

If the supply cable gets damaged, have it replaced by a specialized

service center in order to avoid dangerous situations. It is

prohibited to use an appliance with the supply cable damaged.

Do not leave the door in the open position to prevent the risk of

tripping.

When storing dishes into the dishwasher:

- WARNING: Knives and other utensils with sharp points

and edges must be placed in the basket with points facing

downwards or stored horizontally.

- Sharp items should be placed so that they cannot damage the

door gasket.

EN - 3

- Knives and other similar sharp items should always be placed

with their handles pointing upwards so that the sharp edge

would not hurt anybody.

- Do not use the dishwasher to wash plastic items that have

not been labeled as dishwasher safe by the manufacturer. The

presence of plastic dishes in the dishwasher causes worsening

of drying process results. Please adhere to the manufacturer’s

recommendations regarding plastic items that have not been

labeled as dishwasher safe.

THIS APPLIANCE IS INTENDED TO BE USED ONLY IN

HOUSEHOLDS AND NOT IN SIMILAR PREMISES, SUCH AS:

– kitchenettes in shops, oces and other workplaces;

– agricultural facilities;

– hotels, motels, and other accommodation facilities where

appliances are used by guests;

– bed and breakfast facilities.

• Donotsitorstandonthedooranddishbasketsofthe

dishwasher and to not use force during operation.

• Donotplaceanyheavyitemsontheapplianceanddotostand

on the door when it is open. The appliance might tip over

towards the front.

Use only detergents and polishing agents intended to be used with

automatic dishwashers. Never use soap, detergents or washing

agents for manual dish washing.

Make sure to prevent children from accessing detergents and

polishing agents and also open door of the dishwasher that might

contain residues of the agents as they are strongly alcaline and

might be very dangerous.

EN - 4

The appliance, the power cord or the electric outlet must not lie

in, tough or be submerged in water or any other liquid to avoid

electrical hazards.

If the power cord gets damaged, it must be replaced by the

manufacturer, its service technician or another person with similar

qualication so that safety is not jeopardized.

The appliance must not stand on the power cord.

The appliance should be connected to the water supply using a

new hose, not using a hose that has already been used.

Dispose of packaging in a proper manner.

The power cord must not be excessively or dangerously bent or

compressed during installation.

The controls are not to be played with.

Make sure that the openings in the bottom part of the appliance

are not blocked by the carpet.

The dishwasher should be used only for the purpose it was

intended for - for washing dishes.

This dishwasher is for interior use only.

PLEASE READ THOSE SAFETY PRECAUTIONS CAREFULLY AND

STORE THEM FOR FUTURE REFERENCE

EN - 5

PART 2: DISHWASHER FEATURES

1. Worktop

2. Upper basket with racks

3. Upper spray arm

4. Lower basket

5. Lower spray arm

6. Filters

7. Rating plate

8. Control panel

9. Detergent and rinse-aid dispenser

10. Salt dispenser

11. Upper basket track latch

12. Upper Cutlery Basket

13. Turbo Drying Unit: This system enhances the drying performance of your dishes.

























EN - 6

PART 3: INSTALLING THE MACHINE

Machine positioning

When positioning the machine, place it in an area where dishes can be easily loaded and unloaded. Do not

put the machine in an area where the ambient temperature falls below 0°C.

Read all warnings located on the packaging before removing the packaging and positioning the machine.

Place the machine close to a water tap and drain. Take into consideration that the connections will not be

altered once the machine is in position.

Do not hold the machine by its door or panel.

Leave an adequate distance around the machine to allow ease of movement when cleaning.

Ensure the water inlet and outlet hoses are not squeezed or trapped and that the machine does not stand

on the electrical cable while positioning. Adjust the feet so the machine is level and balanced. The machine

should be placed on at ground otherwise it will be unstable and the door of the machine will not close

properly.

Water connection

We recommend tting a lter to your water inlet supply in order to prevent damage to your machine due

to contamination (sand, rust, etc.) from indoor plumbing. This will also help prevent yellowing and deposit

formation after washing.

Note printing on the water inlet hose!

If models are marked with 25°, the water temperature may be max. 25 °C (cold water).

For all other models:

Cold water preferred; hot water max. temperature 60 °C.

Water inlet hose

WARNING!

Use the new water inlet hose supplied with your machine, do not use an old machine’s hose.

EN - 7

WARNING!

Use the new water inlet hose supplied with your machine, do not use an old machine’s hose.

WARNING!

Run water through the new hose before connecting.

WARNING!

Connect the hose directly to the water inlet tap. The pressure supplied by the tap should be a minimum

of 0.03 MPa and a maximum of 1 MPa. If the pressure exceeds 1 MPa, a pressure relief valve must be tted

between the connection.

WARNING!

After the connections are made, turn the tap on fully and check for water leaks. Always turn o the water

inlet tap after a wash program has nished.

An Aquastop water spout is available with some models. Do not damage it or allow it to become kinked or

twisted.

Electrical connection

WARNING!

Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a

transformer of 110/220 V and 3000 W between the electrical connection.

Connect the product to a grounded outlet protected by a fuse complying with the values in the

“Technical Specications”table”.

EN - 8

The earthed plug of the machine must be connected to an earthed outlet supplied by suitable

voltage and current.

In the absence of earthing installation, an authorised electrician should carry out an earthing

installation. In the case of use without earthing installed, we will not be responsible for any loss of

use that may occur.

The plug on this appliance may incorporate 13A fuse depending on the target country. (For Example

UK, Saudi Arabia)

Fitting the machine undercounter

If you wish to t your machine undercounter, there must be sucient space to do so and the wiring-

plumbing must be suitable to do so (1). If the space under the countertop is suitable for tting your machine,

remove the worktop as shown in the illustration (2).

WARNING!

The countertop, of which the machine will be placed under, must be stable in order to prevent imbalance.

The top panel of the dishwasher must be removed to t the machine under the countertop.

To remove the top panel, remove the screws that hold it on, located at the rear of the machine. Then, push

the panel 1 cm from the front towards the rear and lift it. Adjust the machine feet according to the slope of

the oor (3).

Fit your machine by pushing it under the counter taking care not to crush or bend the hoses (4).

WARNING!

After removing the top panel of your dishwasher, the machine should be placed in a space of the

dimensions shown in the gure below.
