Front Runner RRAC119 Manuel utilisateur

RRAC119

ENG

5 min

IMPORTANT WARNING!

Thank you for purchasing a Front Runner Thru Axle Adapter for Fork Mount Bike Carriers.

Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.

Refer to Page 2 for a list of all the components, quantities and tools required.

READ ME !

Thru Axle Adapter

for Fork Mount Bike Carrier

IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD

RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT

RUNNER PRODUCTS TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND

DAMAGE. THEREFORE YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO

INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY

FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

RRAC119_REV_A00

FIGURE 1.1

1 1 X Thru Axle Adapter

2 1 X Boost Hub Insert

IN THE BOX

GET ORGANIZED

RRAC119_REV_A00

FIT AND SECURE

For fork & wheel sets ﬁtted with Boost

Hubs. Insert Boost Hub insert into

20mm tube.

4MM

2.1

2.2

2.3

Loosen quick release on fork mount.

Place Thru Axle Adapter onto fork mount.

Adjust quick release accordingly and

position Thru Axle Adapter to appropriate

angle. Securely fasten quick release.

Fit RRAC040 to your Front Runner Roof Rack

or Front Runner Load Bars.

*Please see RRAC040 ﬁtment guide for

details.

Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam

Share your adventures on:

FIT AND SECURE

2.4

INSTALL OTHER VEHICLE AND RACK ACCESSORIES

Now's the time to visit your favorite Front Runner Dealer in person or Online.

COMPLETION

3.1

Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.

Please call us if you have any questions about the installation of this product.

Congratulations! You did it. Take a step back and admire your work!

15mm Thru Axle position

20mm Thru Axle position

15mm Thru Axle with Boost Hub
